China Electrical Products Manufacturer IP20 Super Thin LED Driver 50W 700mA Constant Current LED Lighting Drivers
China Electrical Products Manufacturer IP20 Super Thin LED Driver 50W 700mA Constant Current LED Lighting Drivers Specification:Model:YSL50FPower:50W max.Input:100-240VAC 50/60HzOutput Voltage:3-48VOutput Current:10MA-5550MAInrush Current:65 Amps max. at 230VAC/50Hz,full loadLeakage Current:2.5mA M......
Send Inquiry
Product Description
China Electrical Products Manufacturer IP20 Super Thin LED Driver 50W 700mA Constant Current LED Lighting Drivers
Specification:
| Model: | YSL50F |
| Power: | 50W max. |
| Input: | 100-240VAC 50/60Hz |
| Output Voltage: | 3-48V |
| Output Current: | 10MA-5550MA |
| Inrush Current: | 65 Amps max. at 230VAC/50Hz,full load |
| Leakage Current: | 2.5mA Max. at 264VAC input |
| No Load Power Consumption : | <0.5W |
| Protections: | Short Circuit /Over Current /Over Voltage/over temperature protection |
| Short Circuit Protection (SCP): | Protection to Zero Voltage |
| Over Voltage Protection (OVP): | ≤Vout*150% |
| Over Current Protection (OCP): | 110%-180% |
| Working TEMP.: | -20°C-50°C |
| Working Humidity: | 5%-90% RH non-condensing |
| Storage TEMP.,Humidity and altitude: | -40 ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL. |
| Certificates and approvals: | CE,EMC,RoHS,REACH |
| EMI EMISSION: | Conducted disturbance at mains terminals:EN 55015Radiation Test&Conduction Test: EN 55015Magnetic Emission:EN55015:2013 Harmonic Test : EN 61000-3-2 Voltage fluctuation and Flicker Test : EN 61000-3-3 |
| EMS IMMUNITY: | ESDTest:IEC 61000-4-2 RSTest:IEC 61000-4-3 EFT/B ImmunityTest:IEC61000-4-4 Surge Immunity :IEC61000-4-5 Conduted RF Immunity:IEC 61000-4-6 Power frequency magnetic field:IEC 61000-4-11Voltage dips and interruptions,100% reduction: IEC 61000-4-11Voltage dips and interruptions,30% reduction: IEC 61000-4-11 |
| MTBF: | 100000 hours minimum at full load at 25 ambient |
| Life: | 3-5 years alternative |
| Dimension: | 160*58*18mm |
| Packing: | 100pcs/CTN37.5*34.5*23.5cm |
Details:
| Model: | YSL50F-700mA | YSL50F-1050mA | YSL50F-1400mA | YSL50F-2100mA |
| Rated Current: | 700mA | 1050mA | 1400mA | 2100mA |
| voltage Range: | 48-71V | 28-47V | 20-36V | 12-24V |
| Rated Power: | 50W | 50W | 50W | 50W |
| Ripple & Noise(max.): | <1% | <1% | <1% | <1% |
| Voltage Tolerance: | ±5% | ±5% | ±5% | ±5% |
| Line Regulation: | ±3% | ±3% | ±3% | ±3% |
| Load Regulation: | ±5% | ±5% | ±5% | ±5% |
| Efficiency: | 88% | 88% | 88% | 88% |
| Setup,Rise time | 1 second max./40 MS max. | |||
