IP66 Outdoor Door Triac Dim 36 Watt High Power EMC Waterproof LED Driver ENEC SAA RoHS

Product Description

IP66 outdoor door triac dim 36 watt high power emc waterproof LED driver ENEC SAA RoHS

Feature

·Output constant voltage

·Range: 200-240VAC

·Built-in active PFC function Power Factor: up to 0.96

·Efficiency up to 80%

·Dimming range: 0-100%

·Load: 10-100%

·Protection:short circuit/over loading/ Over temperature

·PWM output, does not change the color index

·Full protection plastic case, IP66for indoor and outdoor installation

·Flicker-free

·Compatible with leading edge and trailing edge TRIAC dimmers

·Cooling by free air convection

·Suitable for LED lighting and moving sign applications

Specification

Model		KVF-12036-TDHL	KVF-24036-TDHL
Output	DC Voltage	12V	24V
	Voltage Tolerance	±0.5V
	Voltage Regulation	± 0.5%
	Rated current	3A	1.5A
	Rated power	36W
	Load Regulation	±2%
Input	Voltage Range	200-240VAC
	Frequency Range	47 - 63Hz
	Power Factor(Typ.)@ full load	PF≥0.96/230VAC
	THD(Typ. ) @ full load	<20%
	Efficiency(Typ.)@ full load	80%	80%
	AC Current(Max.)	0.23A/200VAC	0.23A/200VAC
	Inrush Current (Typ.)	34A,50%,104us@230VAC
	Leakage current	<0.5mA
Protection	Short Circuit	shut down o/p voltage, re-power on to recover after fault condition removed
	Over Load	≤120% shut down o/p voltage, re-power on to recover after fault condition is removed
	Over temperature	100ºC±10ºC
	Protection Class	I
Others	Net Weight	0.35Kg
	Dimension	2603220mm(LWH)
	packing	30pcs /CTN SIZE: 290X270X160mm
Notes	1. All parameters NOT specially mentioned are measured at 230VAC input , rated load and 25ºCof ambient temperature. 2. Tolerance: includes set up tolerance, line regulation and load regulation . 3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final equipment manufactures must be-qualify EMC Directive on the complete installation again.
