Ki -423500-Da 3500mA 150W IP66 Constant Current Dali Dimmable LED Driver

Product Description

KI-423500-DA 3500mA 150W IP66 Constant Current DALI Dimmable LED Driver

Feature

·Output constant Current

·Range 100-265VAC

·Built-in active PFC function

·Efficiency up to 88%

·Protections:short circuit/over load/over temperature

·Cooling by free air convection

·IP66 design for indoor and outdoor installation.

·Dimming function: Built in DALI interface dimming function conform to DALI Protocol IEC62386

·Dimming range from 1% to 100%

·Suitable for intelligent LED lighting

·Compliance to worldwide safety regulations for lighting

·Suitable for dry and wet locations

Specification

Model		KI-702100 -DA	KI-602500 -DA	KI-502800 -DA	KI-503100 -DA	KI-423500 -DA	KI-364200 -DA
Output	Rated Current	2100mA	2500mA	2800mA	3100mA	3500mA	4200mA
	Current Tolerance	±5%
	DC Voltage	49-70V	42-60V	35-50V	35-50V	29-42V	25-36V
	Open Circuit Voltage (Max.)	75V	65V	55V	55V	48V	40V
	Rated Power	147W	150W	140W	155W	147W	151.2W
Input	Voltage Range	100-265VAC
	Frequency Range	47~63HZ
	Power Factor	PF≥0.98/120VAC PF≥0.98/230VAC PF≥0.95/265VAC(Full loading)
	Full Load Efficiency (Typ.)	88%	88%	88%	88%	88%	88%
	AC Current(Max.)	1.46A	1.49A	1.39A	1.54A	1.46A	1.50A
	Leakage Current	<0.5mA
Protection	Short Circuit	Protection type: Hiccup mode, recovers automatically after fault condition is removed
	Over Load	≤ 120%
	Protection Class:	I
	Over Temperature	100ºC±10ºC shut down o/p voltage, re-power on to recover
Environment	Working TEMP.	-40 - +60ºC
	Working Humidity	20 - 95%RH,non-condensing
	Storage TEM.,Humidity	-40 - +80ºC,10 - 95%RH
	TEMP.Coefficient	±0.03%/ºC(0 - 50ºC)
	Vibration	10 - 500Hz, 5G 12min./1 cycle, period for 72min.each along X,Y,Z axes.
Safety & EMC	Safety Standards	EN61347-1 EN61347-2-13 IP66
	Withstand Voltage	I/P-O/P:3.75KVAC I/P-FG:1.88KVAC O/P-FG:0.5KVAC
	Isolation Resistance	I/P-O/P I/P-FG O/P-FG:100MΩ/500VDC/25ºC/70%RH
	EMC Emission	EN55015,EN61000-3-2 (≥60%load)
	EMC Immunity	EN61000-4-2,3,4,5,6 ,11,EN61547,A light industry level (surge4KV)
Others	Weight	1.6Kg
	Dimension	2567847mm(LWH)
	Packing	340280185mm/10pcs/CTN
Notes	All parameters NOT specially mentioned are measured at 230VAC input , rated load and 25ºCof ambient temperature. Tolerance: includes set up tolerance, line regulation and load regulation . The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final equipment manufactures must be-qualify EMC Directive on the complete installation again.
