The concept and function of Multilayer Board

Concept:

A multilayer board is a type of printed circuit board (PCB) that consists of three or more layers of conductive material (usually copper) separated by insulating material (dielectric layers) and laminated together under high temperature and pressure. Unlike single- or double-layer PCBs, multilayer boards have internal signal, power, and ground planes, enabling more complex circuitry in a compact form.

Common multilayer configurations: 4, 6, 8, 10, 12, 16, or more layers.

Layers are symmetrically arranged for balance and to prevent warping.

Function and Advantages:

Increased Circuit Density:

Supports more complex designs with higher component density.

More routing space allows for advanced digital and analog circuits.

Improved Electrical Performance:

Shorter signal paths reduce inductance and noise.

Power and ground planes enhance signal integrity and electromagnetic compatibility (EMC).

Compact Size:

Saves physical space in devices by stacking layers vertically.

Ideal for smartphones, computers, medical devices, and aerospace systems.

Design Flexibility:

Allows separation of analog, digital, power, and ground layers.

Enables controlled impedance and differential pair routing for high-speed signals.

Enhanced Reliability:

Better thermal management and structural integrity.

Reduced risk of crosstalk and interference.
