(GN24- 12D ) Indoor AC High Voltage Disconnect Switch

GN24-12D Indoor AC High Voltage Disconnect Switch

1. GN24-12(D) disconnect switch is an indoor electric apparatus of rated voltage 12kV, three-phase AC 50/60Hz which is used to make, break and transfer between lines under situations with voltage and no-load.
2. The innovative structure which the disconnector is also fabricated with an earthing switch.
3. The switch also can be mounted through the wall.
4. Reasonable and scientific design, innovative structure
5. Contacting points distribute on two planes, small operation moment, strong pressure release capability, easy adjustment.
6. Improved driving and conducting parts.
Conditions of Use
1. Altitude :1000m,
2. ambient air temperature : not higher than +40 °C, not lower than -25 °C,
3. Relative humidity: daily average of not more than 90% , month average less than 90%,
4. No fire , explosion, corrosion of metal , insulation damage harmful gases and conductive dust place.

Main Features :



1. Reasonable and scientific design, innovative structure.
2. Contacting points distribute on two planes, small operation moment, strong pressure release capability, easy adjustment.
3. Improved driving and conducting parts.

TECHNICAL SPECIFICATION
