Fn12 Indoor AC High Voltage Load Break Switch
ApplicationFN12-12 series high voltage AC Vacuum load switch is applied in the three-phase, AC50Hz, rated voltage up to 12KV electric supplying network. Mainly applied in three-phase RMU net pr ending electric-supply city distribution station and industrial electrical equipments, with load-control ......
Send Inquiry
Product Description
Application
FN12-12 series high voltage AC Vacuum load switch is applied in the three-phase, AC50Hz, rated voltage up to 12KV electric supplying network. Mainly applied in three-phase RMU net pr ending electric-supply city distribution station and industrial electrical equipments, with load-control and short-circuit protection.
FNR12-12 series high voltage AC Vacuum load switch is applied in the three-phase, AC50Hz, rated voltage up to 12KV electric supplying network. The load switch and combination equipments own obvious isolation fractures, can match earthing switch of CO capacity and electric spring mechanism.
Can realize remote control.
Specification
Packing and shipping
-- Wooden box for products.
-- Shipping mark according to customer's request.
-- Bulk production will be deliveried by sea and air.
Our Service
-- We have our own factory, professional manufacturer
-- We can send you samples within one week.
-- We do OEM & ODM services .
-- We control quality strictly, quality problem: 100% compensation or change
Warmly welcome to visit our factory. Welcome customer or your agent to inspect before order or lading.
FN12-12 series high voltage AC Vacuum load switch is applied in the three-phase, AC50Hz, rated voltage up to 12KV electric supplying network. Mainly applied in three-phase RMU net pr ending electric-supply city distribution station and industrial electrical equipments, with load-control and short-circuit protection.
FNR12-12 series high voltage AC Vacuum load switch is applied in the three-phase, AC50Hz, rated voltage up to 12KV electric supplying network. The load switch and combination equipments own obvious isolation fractures, can match earthing switch of CO capacity and electric spring mechanism.
Can realize remote control.
Specification
| Rated Voltage | 12KV |
| Rated Current | 630A |
| Rate Frequecy | 50Hz |
| Power frequency withstand voltage(1min) | arc extinguishing chamber fracture: 30KV phase, to earth: 42KV; isolation fracture: 48KV |
| lightning impluse withstand voltage(peak) | Vacuum arc-extinguishing chamber fracture: 60KV phase, to earth: 75KV; fracture: 85KV |
| Rated short-time withstand current(Moving reliable current) | 20KA |
| Rated short-circuit duration | 4s |
| Rated peak withstand current(Moving reliable current) | 50KA |
| 5% rated active power breaking current | 31.5A |
| Rated cable charging current | 10A |
| Rated active power load breaking current | 630A |
| Rated close-loop breaking current | 630A |
| Rated cable breaking no-load transformer capacity | 1600kVA |
| Rated short-circuit clsoing current | 50kA |
| Earthing switch rated short-time withstand current(thermal reliable current) | 20kA |
| Earthing switch rated short-circuit duration | 2s |
| Earthing switch thermal reliable current | 20kA |
| Earthing switch rated peak withstand current(Moving reliable current) | 50kA |
| Auxiliary circle rated voltage | AC,DC 220V/110V |
| Mechanism life | 10000 times |
| Rated active power load current breaking times | >100 times |
| Vacuum extingushing chamber conact admitted wearing thickness | 2mm |
