Factory Price 50/60Hz AC Starter Motor Price
SE1 series Magnetic starteris mainly applied to circuit of AC 50 or 60Hz,voltage up to 550V for far distance making and breaking circuit and frequently starting and controlling motor. It hasthe features of small volume, light weight, low power consumption, high efficiency, safe and reliable performa......
Send Inquiry
Product Description
SE1 series Magnetic starteris mainly applied to circuit of AC 50 or 60Hz,voltage up to 550V for far distance making and breaking circuit and frequently starting and controlling motor. It hasthe features of small volume, light weight, low power consumption, high efficiency, safe and reliable performance.
Specification:
Our Services:
Specification:
| Type | Rated Current(A) | Maximum Power AC3 duty (KW) | Type of enclosure | SuitableThermal Relay(A) | |||||
| 220V 230V | 380V 400V | 415V | 440V | 500V | 660V 690V | ||||
| SE-D09 | 9 | 2.2 | 4 | 4 | 4 | 5.5 | 5.5 | IP42 IP65 | LR2 D1312 LR2 D1314 |
| SE-D12 | 12 | 3 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | LR2 D1316 | |
| SE-D18 | 18 | 4 | 7.5 | 9 | 9 | 10 | 10 | LR2 D1321 | |
| SE-D25 | 25 | 5.5 | 11 | 11 | 11 | 15 | 15 | LR2 D1322 LR2 D2353 | |
| SE-D32 | 32 | 7.5 | 15 | 15 | 15 | 18.5 | 18.5 | IP55 | LR2 D2355 |
| SE-D40 | 40 | 11 | 18.5 | 22 | 22 | 22 | 30 | LR2 D3353 LR2 D3355 | |
| SE-D50 | 50 | 15 | 22 | 25 | 30 | 30 | 33 | LR2 D3357 LR2 D3359 | |
| SE-D65 | 65 | 18.5 | 30 | 37 | 37 | 37 | 37 | LR2 D3361 | |
| SE-D80 | 80 | 22 | 37 | 45 | 45 | 55 | 45 | LR2 D3363 LR2 D3365 | |
| SE-D95 | 95 | 25 | 45 | 45 | 45 | 55 | 45 | LR2 D3365 | |
Our Services:
- Competitive price
- Continuance Service and support
- Good-after service
- Quality Reliability and Long Product Life.
Thanks for your reading.If any product meets your need.Welcome to send us an email.We are sure your any information can be attentioned without any delay.
