DIN Rail Mounting Phase Faliure and Sequence Relay with CE
Phase Faliure and Sequence Relay (MK-05P)Specifications:1)Rated voltage: 3 phase 380V and neutral 230VAC2)Function: The protection from the phase failure, phase sequence, voltage unbalance3)Contact capacity: AC220V 5A/AC 380V, 3A4)Electrical life: 100000times5)Mechnical life: 1000000times6)Installat......
Send Inquiry
Product Description
Phase Faliure and Sequence Relay (MK-05P)
Specifications:
1)Rated voltage: 3 phase 380V and neutral 230VAC
2)Function: The protection from the phase failure, phase sequence, voltage unbalance
3)Contact capacity: AC220V 5A/AC 380V, 3A
4)Electrical life: 100000times
5)Mechnical life: 1000000times
6)Installation: Rail.
Technical Data
Rated voltage(Un): 3 phase and neutral 230VAC
4 wires star connection
Operating range: (0.9~1.1)*Un
Rated Frequency: 50/60Hz
Output contacts: 1C/O with 5A, 1250VA(for MK-01P)
1C/O with 8A, 2000VA
Warning LED: Green LED: Normally ON (turns OFF on faults)
Tripping time: 0.2s
Ambient temperature: -5º C~+50º C
Protection class: IP20
Flow Path
Specifications:
1)Rated voltage: 3 phase 380V and neutral 230VAC
2)Function: The protection from the phase failure, phase sequence, voltage unbalance
3)Contact capacity: AC220V 5A/AC 380V, 3A
4)Electrical life: 100000times
5)Mechnical life: 1000000times
6)Installation: Rail.
Technical Data
Rated voltage(Un): 3 phase and neutral 230VAC
4 wires star connection
Operating range: (0.9~1.1)*Un
Rated Frequency: 50/60Hz
Output contacts: 1C/O with 5A, 1250VA(for MK-01P)
1C/O with 8A, 2000VA
Warning LED: Green LED: Normally ON (turns OFF on faults)
Tripping time: 0.2s
Ambient temperature: -5º C~+50º C
Protection class: IP20
Rated voltage | 3 phase and neutral 230VAC |
| 4 Wires star connection | |
| Operating range | (0.9-1.1)×Un |
| Rated frequency | 50/60Hz |
| Output contacts | 1 C/O with 5A,1250VA(for MK-01P) |
| 1 C/O with 8A,2000VA | |
| Warning led | Green LED: normally ON(turns OFF on faults) |
| Tripping Time | 0.2s |
| Ambient temperature | -5ºC~+50ºC |
| Protection class | IP20 |
| Dimension | Surface mounting or on the mounting rails |
Flow Path
