Ssrda4850 DC to AC 480VAC Solid State Relay
.Solid State Relay Model No. : XSSR-DA4850 Input and output electro-optic isolation or transformer isolation; input constant current control and LED display , contril signal and TTL & CMOS logic is compatible; Bidirectional controlled sillion or unidirectional controllable counter-parallel outpu......
Send Inquiry
Product Description
.
Solid State Relay Model No. : XSSR-DA4850
Input and output electro-optic isolation or transformer isolation;
input constant current control and LED display , contril signal and TTL & CMOS logic is compatible;
Bidirectional controlled sillion or unidirectional controllable counter-parallel output , zero electric current shutdown;
Power solid state uses the SCR chip counter-parallel output and working is stable ;
Buit-in resistance-capacitance absorbing ciruit, dead zone voltage between the input output and l;edger wall's;
Small volume,small input power , non-contact , sparkless , noiseless , non-machinery wear , anti-vibration and the long life
| Control voltage | 3-32VDC | 80-250VAC |
| Control vurrent | 6-25mA | 5-25mA |
| Reverse voltage | 32VDC | / |
| Guarantee colse voltage | 1VDC | 30VAC |
| Guarantee open voltage | 3VDC | 80VAC |
| Load voltage | 24-240VAC 70-480VAC | |
| Load max current | 10-100A | |
| Load min current | 0.05A | |
| Breakover voltage | ≤2VAC | |
| Output leakage current | ≤5mA | |
| Medium with stand voltage | ≥2500VAC | |
| Insulating resistance | ≥100MΩ | |
| Switching time | ≤10ms | |
| freuquency range | 50-60Hz | |
| Operating temperature | -20-70ºC | |
| load current safety factor | Resistive load 50-60% | |
| Inductive load30-40% | ||
