(LZZB1-24W) Outdoor Epoxy Cast-Resin 500A 5p 15va Current Transformer

Product Description

LZZB1-24w CURRENT TRANSFORMERS
TECHINCAL DATA
The products accord with the standards of IEC60044-1:2003 and some special demands.
Rated insulation 24/65/125KV
Rated Frequency 50HZ/60HZ
Rated Secondary Current 5A or 1A
Ambient Temperature -5ºC~ +40ºC

Rated primary current(A)	Accuracy classes combination	Rated output(VA)				Rated short-time thermal current(KA/1S)	Rated dynamic current(KA)
		0.2s	0.2 0.5s	0.5	5P
20~40	0.2S/0.5 0.2/0.5 0.2/5P10 0.5/5P10 0.2/5P10 0.5/5P10	10	15	15	15	250I1n	625I1n
50~100						300I1n	750I1n
150~250						40	100
300~2500		15		20		63	160
10~200	0.2S/5P20 0.2/5P20 0.2S/5P20 0.2/5P20	10	15	15	15	150I1n	375I1n
300~500						40	100

Note: If user's data go beyond the above mentioned scopes, they may be subject to an agreement between mannufacturer and purchaser.
