0.5~2000A Electrical Control Current Transformer for Battery Banks Factory Price CT
13mm 20A Mini precision current transformer Solid core CTThe ECH100 Series current transformer is compact.smaller than other models with the current ratio of the transformer is small, clamshell-style terminal cover is well protected by the second terminal. With related accessories you can use Din ra......
Send Inquiry
Product Description
13mm 20A Mini precision current transformer Solid core CT
The ECH100 Series current transformer is compact.smaller than other models with the current ratio of the transformer is small, clamshell-style terminal cover is well protected by the second terminal. With related accessories you can use Din rail mounting
Customized current ratio available.
MODEL | INPUT CURRENT | AVAILABLE OUTPUT |
ECH100-600 | 600A | CURRENT OUTPUTS @50mA, 100mA, 1A, 5A VOLTAGE OUTPUTS @0.333V, 0.5V, 1V, 2V, 5V |
| ECH100-800 | 800A | |
ECH100-1000 | 1000A | |
ECH100-1200 | 1200A | |
ECH100-1500 | 1500A | |
ECH100-2000 | 2000A |
Applications:
Current measurement
Monitoring and protection
Energy and sub-metering products
Network equipment
Instruments and sensors
Control systems
Advantage:
Excellent linearity over the whole range.
Fully RoHS compliant.
