China Lzzbj9-10 (D1 D2) Indoor 2000A 0.2s 20va Current Transformer

Product Description

LZZBJ9-10(D1'D2) CURRENT TRANDFORMERS
TECHNICAL DATA
The products accord with the standards of ICE60044-1:2003 and some special demands.
Rated insulation 12/42/75KV
Rated Frequency 50HZ
Rate Secondary Current 5A or 1A
Ambient Temperature -5ºC~ +40ºC

Rated Primary current(A)	(KA Virtual Value)I 1h/1s	(KA Peak ) Idyn	Accuracy classes Combination	Rated Secondary Output(VA)
Rated Primary current(A)	(KA Virtual Value)I 1h/1s	(KA Peak ) Idyn	1S/2S/3S/4S	0.2(s) 0.5s	0.5	5P20
50	21	52.5	0.2(S)/5P20 0.5(S)/5P20 0.2(S)/0.5(S)/5P20/5P20	10	15	20
75	22	55
100,150	40	78
200	37.8	94.5
250	40	100
300	50.4	126
400~630	63	130
1500,1600	63	130
2000	80	200

Note: If user's data go beyond the above mentioned scopes, they may be subject to an agreement between mannufacturer and purchaser.
