Product Description

Factory Custom High frequency ferrite core flyback transformer Pq2620 strong power switching transformer SMPS high frequency transformer free sampl

1. Their input voltage can be different to meet requirements of various regions: AC380V-240V-230V-220V-120V-110V-100V.
2. Special designs are also available to meet customers' requirements.

Power Capacity Chart:
Power range (W)Core type using N67* grade material
<5RM4; P11/7; EF12.6; U10
5-10E(F)16; RM5; P14/8
10-20RM6; E(F)20; P18; U15; EFD15
20-50RM8; P22; RM10 ETD29; E25; EFD20
50-100ETD29; ETD34; RM12; P30; EFD25
100-200ETD34; ETD39; ETD44; P36; E30; E42; EFD30
200-500ETD44; ETD49; E55
>500ETD54; ETD59; E65
PQ20. PQ32. PQ35 etc.
Their input voltage can be different to meet requirements of various regions: AC380V-240V-230V-220V-120V-110V-100V.
The power capacity of each core type varies due to differences in topology, operating frequency and temperature, flux density, and material grade.

Key Features:
1. Operating Frequency: 50~200KHz
2. Low-cost, all models mainly used in less demanding fields on the electromagnetic shielding power field.
3. Power frequency because of work, safety regulations and other requirements of the different temperature level will change.
4. Large transmission power
5. wide frequency reange
6. stable performance
6. Low Temperature rise

Main Application:
1. High Frequence transformer have been widely used in many electronic facilities and equipment
2. Electronic apparatus, aerocraft, transmilter, computer.
3. Communication equipment and TV etc.

Our products

NO.

Product Name

Type

Detailed Size

1

High frequency transformers

EE

EE8.3, EE10, EE13, EE16, EE19, EE20, EE25, EE28, EE30, EE33, EE40, EE42, EE49, EE50, EE55, EE60, EE65, EE70, EE75, EE80, EE85

EC/ER

ER/EC20, ER/EC25, ER/EC28, ER/EC28, ER/EC29, ER/EC35, ER/EC40, ER/EC42, ER/EC49

ETD

ETD29, ETD35, ETD40, ETD49

EF

EF16, EF20, EF25

EFD

EFD15, EFD20/21, EFD25/26, EFD30

EDR

EDR2009, EDR2037, EDR2809, EDR2828, EDR3012, EDR3909, EDR4008

EP

EP7, EP10, EP13

EPC

EPC11.5, EPC13, EPC19, EPC25

EQ

EQ2512, EQ2610, EQ3209, EQ4013,

POT

POT3016, POT3930

PQ

PQ2016, PQ2020, PQ2625, PQ2620, PQ3225, PQ3520, PQ3525, PQ3535, PQ4040, PQ49

RM

RM6, RM8, RM10, RM12, RM14

2

Common mode chokes(Line filters)

UU

UU9.8, UU10.5, UU16

ET

ET20, ET24, ET28, ET35

SQ

SQ1212, SQ1515, SQ2418

FT

FT20-22, FT20-21, FT20-15, FT20-13, FT20-10

Toroidal

6X3X2, 6X3X3, 8X5X3, 9X5X3, 9X5X4, 10X6X3, 10X6X3.5, 10X6X5, 13X8X6, 14X9X5, 20X12X6, 22X14X8, 25X15X10, 5X15X12, 25X15X13, 28X14X10, 31X19X11, 31X19X13, 32X14X11,36X23X15, 38X18X13, 49X32X16 (Ferrite core); 16X10X6, 20X12.5X8, 25X16X10, 30X20X10, 30X20X15, 40X25X15, 50X40X20, 63X50X25, 80X63X25, 100X80X25, 130X100X25(Nanocrystalline core)

3

Inductors(Choke coils)

Peaking/Drum

4*6, 5*7, 6*8, 8*10, 9*12, 10*12, 10*16, 14*15, 16*18, 18*20

Toroidal

6X3X2, 6X3X3, 8X5X3, 9X5X3, 9X5X4, 10X5X4,10X6X3, 10X6X3.5, 10X6X5, 13X8X6, 14X9X5, 20X12X6, 22X14X8, 25X15X10, 25X15X12, 28X14X10, 31X19X11, 31X19X13, 32X14X11,36X23X15, 38X18X13, 49X32X16

Rod

3X12, 3X15, 4X15, 4X20, 5X15, 5X20, 5X25, 5X30, 6X15, 6X20, 6X25, 6X30, 6X32, 6X35, 8X20, 8X30

4

SMD power inductors

Unshielded

MT, MTQ, MTF, MTG

Shielded

MTH, MTHII, MTP, MTB, MTE, MTL, MTF

5

Low frequency transformers

EI

EI14, EI16,EI19, EI24,EI28, EI30, EI35, EI38.5, EI41,EI48, EI57, EI60, EI66, EI74, EI76, EI86, EI96, EI105, EI114

Toroidal

OD:40mm---130mm;ID:20mm---100mmm;H:10mm---50mm.

6

Planar transformer

EI

Ei22

7

CT

UF

UF15,Zero sequence current transformer, precision current transformer

8

Coil

T

185*60,23.8

Related Products

The company is a trustworthy enterprise integrating R&D, production and sales. It specializes in the production of high-frequency transformers, low-frequency transformers, toroidal transformers, rectifiers, power adapters, and switching power supplies. It has independent legal personality, a registered capital of 3 million, and the company's products cover Household appliances, medical fitness equipment, communications, instrumentation, security, industrial control and other fields, widely used in computers, mobile phones, audio, TV, air conditioners, telephones, microwave ovens and various instruments, welding machines, security monitoring and other industries . It has been spread all over the country in various provinces, municipalities, autonomous regions, and municipalities directly under the Central Government. Some products are exported overseas.

Equipment Exhibition

Our main equipments contained: 256 sets of automatic winding machines; 2 sets of automatic infrared drying tunnel furnace; the lab for car magnetic products; 1set of salt spray test machine,1 set of high-temperature storage test machine, 1 set of high humidity test machine and a set of old and heat shock test machine; 6 sets of automatic vacuum dipping machines; 3, fully automatic soldering machines, 600 set accessory Machines.

Factory Custom High Frequency Ferrite Core Flyback Transformer Pq2620 Strong Power Switching Transformer SMPS High Frequency Transformer Free Sample

Company Advantages

1. We are a professional Magnetic component manufacturer with over 16 years of experience in designing and producing and Exporting.
2. Big production capacity: The factory acreage is about 24800 square meters, total production capacity reached 8 million pieces of transformer series per month.
3. Strictly QC inspecting rules: all products must be 100% inspected before delivery.
4. OEM/ODM services are available.

Factory Custom High Frequency Ferrite Core Flyback Transformer Pq2620 Strong Power Switching Transformer SMPS High Frequency Transformer Free Sample
Kindly reminder: This is cu
Kindly Reminder:

1. About the SAMPLES. Please provide specific specifications or sample material, we will evaluate your products, design and produce samples.
2. About PRICE. Transformers are custom products, due to the different materials and design, even if the same model, the price is not the same. The price also depends on the complexity of the parameters and the amount of orders.
3. About SHIPPING. Samples in 3-5 days; mass production in 7-15 days.
4. Packaging, logistics, according to the specific requirements of the purchase and sale contracts.
5. We have an independent order system, with the overall tracking function from raw materials purchasing to finished goods outgoing.
6. We have got ISO9001:2015 quality management system; ISO14001:2015 environment management system; health and safety management systems-Requirement, IATF16949, UL certification.
7. Independent laboratory for car magnetic. It meets all the car component test.
8. Our factory can meet various needs

Factory Custom High Frequency Ferrite Core Flyback Transformer Pq2620 Strong Power Switching Transformer SMPS High Frequency Transformer Free Sample

contact details

Zhang Yihui

Shenzhen Yiyi Technology Co.,Ltd
Adress: 501, No.11, Lane 1, Nanzhuang New Village, Xinzhuang Community,
Matian Street, Guangming New District, Shenzhen, Guangdong

Note:
welcome to inquire, tell us the demand parameters, design drawing or material requirements, inductance coil number than leakage inductance angle, voltage withstand input and output voltage and other detailed information, we can customize according to the requirements, please contact before payment, we implement the principle of large quantity first! Please confirm before placing an order, the quantity is different and the price is different.
