Small Electric Transformer PCB Mounting Encapsulated Power Transformer with Pin

Product Description

small electric transformer pcb mounting encapsulated power transformer

PCB mounting transformer
1. Easy to install.
2. Lower power consumption.
3. Little temperature rising.
4. High accuracy of output voltage.
5. Diemension and output leads can be customized.
6. Dielectronic Strength is high.

Product Specification:
1. Models: EI28, EI30, EI35, EI48, EI57, EI66, EI86, EI96, EI105, EI114, EI133, EI152, EI162 etc.

2. Maximum output: 1.2W, 2W, 12W, 20W, 35W, 40W, 50W, 90W, 180W, 200W, 400W, 600W, 850W, 1500W, 2400W, 2700W etc.

3. Input: 100Vac, 110Vac, 115Vac, 120Vac, 220Vac, 230Vac, 240Vac etc.

4. Output: AC(0--380V); DC(0--50V)

ITEM	MODEL	DIMENSIONmm			REF VA		WEIGHT
ITEM	MODEL	A	B	C	f= 50KHz	f= 100KHz	g
1	EI-10	11	10	9	3	6	8
2	EI-12.5	13	12	10	4	8	10
3	EI-16	17	16	14	5	9	11
4	EI-19	20	19	16	8	13	12
5	EI-22	23	21	18	14	20	16
6	EI-25	26	22	19	20	30	21
7	EI-28	29	22	22.5	42	58	35
8	EI-30	31	29	26	61	95	54
9	EI-35	37	33	28.5	100	150	78
10	EI-40	42	38	29	160	250	110
11	EI-44	46	41	33	260	391	150
12	EI-50	52	44.5	38	430	650	195

Application
1. Measuring instruments.
2. Communication prducts.
3. Medical instruments.
4. Audio & Video
5. Elevator
6. Machinery
Parameter
